Description
Model: BK8885
Model: BK8885U (USB+Adapter)
Model: BK8885W (Wireless)
Model: BK8885UW(USB+Adapter+Wireless)
Features:
1)USB Port provides excellent user interface (BK8885U/ BK8885UW)
2)DC 12V adapter (BK8885U/ BK8885UW)
3)Wireless two ways transmission (BK8885W/ BK8885UW)
4)Maximum 40000 counts
5)Dry and liquid pressure measuring
6)HVACR application superheat and subcooling
7)Easy temperature coefficient compensation
8)T/C offset adjustment user-selectable
9)Automatic power off battery saver
10)Maximum overload pressure= 800 psi
11)4 refrigerants tests: R22, 134A, 404A, 410A
12)Backlight function
13)MIN/MAX/MAX-MIN/HOLD functions
Specifications:
Polarity: Automatic, positive implied, negative polarity
indication.
Low battery indication: The “ ” is displayed when the battery
voltage drops below the operating level.
Measurement rate: 1.5 times/second.
Operating environment: 0°C to 50°C at<80% R.H.
Storage environment: -20°C to 60°C, 0 to 70% R.H. with
battery removed from meter.
Accuracy: Stated accuracy at 23°C±5°C, <75% R.H.
Pressure Range: 29" Hg to 0 to 500 psi.
74 cmHg to 0 to 4000KPa
0 to 200 psi: ±1 psi
0 to 1378 kPa: ±7 kPa
200 to 500 psi: ±0.3%+1 psi
1378 to 4000 kPa: ±0.3%+7 kPa
Battery: 1.5Vx4pcs AAA size.
Dimensions: 160mm(H) x 83mm(W) x 38mm(D).
Weight: approx. 355g including batteries.
Applications:
1)HVAC application
2)HVAC efficiency maintenance
3)Optimal Superheat & Subcooling adjustment.
Temperature Range
Range: -40°C to 204°C, -40°F to 400°F
±(0.5°C) on -40°C to 93°C, ±(1°C) on 93°C to 204°C
±(1°F) on -40°F to 200°F, ±(2°F) on 200°F to 400°F
Accuracy: Stated accuracy at 23°C ± 5°C, <90% R.H.
Operating environment: 0°C to 50°C at <75% R.H.
Temperature Coefficient: 0.1 times the applicable accuracy
specification per °C.
Connector:
Input Connector: Accepts standard miniature thermocouple
connectors (flat blades spaced 7.9mm, center to center).
Pressure: Standard ¼ inch male flare fitting.
Storage temperature: -20°C to 60°C, 0 to 80% R.H. with
battery removed from meter.
Auto Power off: 15 minutes after power off.
(BK8885U/ BK8885UW)
Accessories: USB cable.
12VDC Adaptor.(Option)
(BK8885W/ BK8885UW)
WIRELESS Features:
Frequency range: 910~920MHz.
Low current consumption less than 1mA.
The transmitting distance can reach 25M without magnetic
interference.
-
Fruugo ID:
229850620-490493602
-
EAN:
884132546120
