_x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ Specification: _x000D_ Certification: CE _x000D_ Origin: Mainland China _x000D_ DIY Supplies: ELECTRICAL _x000D_ Display Type: Digital Only _x000D_ Model Number: Digital voltmeter ammeter _x000D_ Shell material: ABS _x000D_ Size: 47.63x28.66x23.74mm/1.88x1.13x0.93in _x000D_ _x000D_ Describe: _x000D_ The M520 is a voltage, current and power measuring instrument: it can only measure and display the voltage, current and power of the circuit under test. The displayed value can be fine-tuned with an adjustable resistor. The actual voltage and current of the loop has no effect. During use, do not work under high voltage above 20V, otherwise it will easily cause overvoltage damage to the product. _x000D_ 10A series products have shunt resistors, and the test terminal for DC measurement will be short-circuited. As long as the instrument is connected in series with the load according to the wiring diagram, it can be used normally. _x000D_ Working voltage: The working voltage of the instrument is DC 5-30V, and it is recommended to be 5-12V. The thin red wire is the positive pole of the working power supply, and the thin black wire is the negative pole of the working power supply, which is on the same ground as the thick black wire; the limit voltage connected to the red and black thin wires cannot exceed 24V, and a 12V power supply is recommended. _x000D_ Measurement range: The voltage measurement range is 0-100V, and the display mode below 10V is 0.0V. The voltage starts at 0.1V and has a tolerance of 1V. The current measurement range is 0-10A, the current starts from 0.03A, and the error starts from 3%. _x000D_ Shunt Resistor: On-board shunt resistor, no need for external shunt, just use it directly according to the wiring diagram. The parallel resistance is connected in parallel with the current test line, and the no-load test will cause a short circuit alarm. When in use, connect the thick red wire to the negative pole of the load according to the wiring diagram of normal use. _x000D_ Standard lead: XH-2.54-3P red, black, yellow wire (the total length of the thin wire is 155mm/6.1in) _x000D_ Red thin wire: the positive pole of the working power supply, cannot be connected to a power supply above 30V _x000D_ Thin black wire: the negative pole of the working power supply, the thick black wire on the construction site, it does not need to be connected when sharing the power supply _x000D_ Thin yellow wire: Voltage test lead, connected to the positive side of the test circuit power supply _x000D_ VH-3.96-2P red and black wire (thick wire total length 165mm/6.5in) current test wire _x000D_ Thick red wire: Positive pole of current test, connected to negative pole of load. _x000D_ Thick black wire: current test negative pole, connect the power supply negative pole, connect first, disconnect then disconnect _x000D_ Voltage display trim: This is a trim trim, not a major adjustment. What is adjusted is the displayed voltage, but the actual voltage cannot be adjusted! _x000D_ Check out V-ADJ's round adjustable resistor, find a flat blade screwdriver and twist it! _x000D_ No-load current does not return to zero _x000D_ Display power _x000D_ Real time power will alternate with current (about 10 seconds alternate) _x000D_ _x000D_ Note: _x000D_ Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you! _x000D_ Please allow 1-2cm measuring deviation due to manual measurement. _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ 1 X Voltmeter _x000D_ 2 X Wires _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_
