HLK-RM20 is a high performance embedded module from . It is a highly integrated system-on-chip router module using MT7981B+MT7531A for home entertainment and home automation,etc. The SOC used are manufactured using advanced silicon processes and integrate the dual-core ARM-A53MPCoreTM, operating at frequencies up to 1.3GHz and more DRAM bandwidth. A variety of peripherals are also included, including SGMII and USB3.0(host) ports. Two 2.5Gbps HSGMII Ethernet interfaces have also been implemented. HLK-RM20's built-in hardware-based NAT engine with , in addition to good connectivity, can also transmit audio and video streams at a higher priority than other non-time-sensitive , enriching home entertainment applications. SFQ separates P2P sessions from audio and video sessions, thus guaranteeing streaming for HLK-RM20. With advanced technology and rich features, HLK-RM20 be the core of generation of smart home gateway systems. Nand Flash/DDR3; InterfaceWAN*1, LAN*5, USB3.0, PCIe Gen2 1- x 1; WAN access methodPPPoE, dynamicIP, staticIP, 3G/4G/5G; Static address allocation, virtual servers, port forwardingDMZ host; Module power supply voltage: DC3.3V5A; Key Features Embedded Dual Core ARM -A53 MPCore 1.3GHz 32KBL1 I-Cache and 32KBL1-D-Cache 256KB unified L2 Cache NEON/FPU: Operating Temperature: -20C to +80 C Relative Humidity: 10-90% (non-condensing) Storage: Temperature: -40C to +85C (non-operating) Relevant Humidity: 5-90% (non-condensing) MTBF caculation:Over 150,000hours Colour:As Shown Material:PC Plug Type:US Plug,it applies to Canada, India,Mexico, Thailand, the , the Philippines,Taiwan and so on. voltage:AC110V Due to different product batches, the appearance , which does not affect the use Package Contents: 1 * Openwrt Gigabit Router Module Kit Only the above package content, other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
